multibase 2072i
Car Stacker

Product Information

The MultiBase 2072i is one of the most comfortable car stacker systems since the offset steel supports mean that vehicles doors can be opened much wider. Compared to the competition, the MultiBase 2072i has an extra 50 mm advantage. It is the perfect choice for all-terrain vehicles and SUVs up to 2,150 mm in height.



Project Documents

Data Sheet – Multibase 2072i (2MB)

TENDER SPECIFICATION – MULTIBASE 2072I (82KB)

DWG – MULTIBASE 2072I (4MB)

REVIT 3D Model – MULTIBASE 2072I (17MB)

Specifications

  • Independent parking
  • 2 levels
  • 2 – 4 spaces per stacker
  • Indoor/Outdoor system
  • Pit depth anywhere from 1,700mm to 2,350mm
  • Pit length 5,200mm/5,400mm
  • Pit width anywhere from 2,600mm to 5,700mm
  • Height anywhere from 3,200mm and up
  • Usable platform width anywhere from 2,300mm to 5,400mm
  • Usable platform length 5,000mm/5,200mm
  • Weight options 2.0t/2.6t/3.0t
  • No gates required due to key switch operation
