mastervario R3
Fully-Automatic System

Product Information

MasterVario R3

The shelf systems are similar to a high-bay warehouse and have a further axis of movement opposite the tower system. Shelving systems are therefore particularly suitable for narrow and long terraces and buildings. The shelving system can also be executed above ground, underground or as a combination of both variants.

MasterVario R3C and R3L

The MasterVario R3 shelving system has the same flexible features as the Tower system, but has a further advantage: an additional axis of movement of the shelf operating unit allows up to ten vehicles to be arranged one behind the other. In this case, the grids can be implemented in a simple, double or even triple manner. Up to 30 parking spaces are possible per park level. Even with this fully automatic parking system, a parking space number of maximum 50 – 60 vehicles per system/transfer cabin must not be exceeded in order to continue to allow fast access times. The type MasterVario R3 is the right choice if you have an elongated plot. From standard cars to SUVs – the MasterVario R3 recognises the height of your vehicle and finds the appropriate parking space. In addition to standard passenger car dimensions and standard passenger car weights, special solutions are also available on request. An individual project adaptation is, of course, possible in many cases.



Project Documents

TECHNICAL INFORMATION – MASTERVARIO (394KB)

QUESTIONNAIRE – FULLY AUTOMATIC SYSTEMS (24KB)

DATA SHEET – MASTERVARIO R3L (2MB)

DATA SHEET – MASTERVARIO R3C (3MB)

MasterVario R3L

MasterVario R3C

Fully-Automatic Parking Systems
Always a Premium Solution

Specifications

  • for maximum 50 – 60 vehicles per system or transfer cabin
  • surface area: oblong
  • above and/or underground
  • up to 10 parking levels
  • up to 30 parking spaces per level
  • vehicle dimensions: length 5,200mm, width 2,150mm (additional dimensions optional), height as required, also two different car heights can be realised
  • standard version: 2,500 kg per parking space, optional higher load on request possible
  • arrangement of the parking spaces: one, two or three rows with up to 10 vehicles next to each other, right and/or left next to the storage unit
  • C – sideways storage
  • L – lengthways storage
  • operation: access control via transponder, remote control
  • transfer booth: arrangement on ground level or in the lower floor
  • transfer of the cars into the storage area via a shelf operating unit with horizontal and vertical conveyor, optionally with additional lateral lift
  • turntable optional

Important Advantages

  • optimal access times
  • secure vehicle accommodation
  • protection against theft and damage
  • safe access to the parking area without narrow ramps or dark accesses
  • reconstructed space can be reduced by up to 50 percent compared to conventional parking spaces
  • space requirements for ramps and lanes are not required
  • saving park levels including their equipment (lighting, ventilation, sprinkler systems)
  • reduction of construction time
  • use of the saved construction volume for additional parking space or more economical purposes
