MultiBase G63 Car Stacker | KLAUS Multiparking

Product Information

With three levels, the MultiBase G63 triples the amount of available parking space. This makes it possible to create up to six parking spaces in extremely tight areas. Depending on the design, this system accommodates vehicles with a height up to 1,700 mm.

Project Documents

Data Sheet – Multibase G63 (515KB)

TENDER SPECIFICATION – MULTIBASE G63 (77KB)

DWG – MULTIBASE G63 (698KB)

DXF – MULTIBASE G63 (1724KB)

Specifications

Independent parking
3 levels
3 – 6 spaces per stacker
Indoor/Outdoor system

Pit depth anywhere from 3,350mm to 3,750mm
Pit length 5,200mm/5,400mm
Pit width anywhere from 2,600mm to 5,400mm
Height anywhere from 4,800mm and up
Usable platform width anywhere from 2,300mm to 5,000mm
Usable platform length 5,000mm/5,200mm
Standard design with 2.0t. Optional max. 2.5t for single platform system.

No gates required due to key switch operation
Horizontal access to all parking levels

Accessories

E Charger

Building Closeup

Upgrades and optional extras available for your KLAUS parking system.

View Accessories

Related Products

MultiBase U3

multibase U3

The MultiBase U3 is a completely retractable system, with up to three lowerable parking spaces, flush to the ground and traversable.

SingleUp 3015

singleup 3015

Three levels of parking can be achieved without the need for a pit. The dependant 3015 provides an ideal combination for long and short-term parking.
