singlevario 2061
Car Stacker

Product Information

Horizontal access to single platform
Outdoor use available
Max load per single platform parking space – 2500kg

The SingleVario 2061 is the base version of the stack parker. This system is ideal in situations where a long-term parker uses the upper platform while a more frequent driver uses the lower platform.



Project Documents

DATA SHEET – SINGLEVARIO 2061 (4MB)

TENDER SPECIFICATION – SINGLEVARIO2061 (73KB)

DWG – SINGLEVARIO 2061 (680KB)

Specifications

  • Dependent parking
  • 2 levels
  • 2 spaces per stacker
  • Indoor/Outdoor system
  • Length 5,200mm/5,400mm
  • Width anywhere from 2,600mm to 3,000mm
  • Height anywhere from 3,200mm and up
  • Usable platform width anywhere from 2,300mm to 2,700mm
  • Usable platform length 5,000mm/5,200mm
  • Weight options 2.0t/2.6t
  • No gates required due to key switch operation

Accessories

Upgrades and optional extras available for your KLAUS parking system.

View Accessories
